Specifications

Voltage

24/48 V, 110/230 V, 50/60 Hz or 24 V DC

Signal Output

Floating microswitch AC max. 250 V, 2 A, 500 W DC max. 300 V, 2 A, 60 W

Enclosure

IP 65

Process Connection

Thread G1 1/4", G1 1/2", G2 1/2"

Material Vane Shaft & Measuring Vane Material

Plastic

Friction Clutch

Protection of the gearing from impact of the measuring vane

Pickup Delay

Appox. 1.3 sec

Sensitivity

Adjustable via reset force of spring in three positions

Speed of Measuring Vane

1 rpm

Container excess pressure

max. 0.8 bar

Temperature inside vessel

-20°C ~ 80°C
